| Product Attribute | Attribute Value |
|---|---|
| Body Style | Rectangular |
| Sensing Mode | Diffuse |
| Series | |
| Supply Voltage | 24-240 VAC ; 12-240 VDC |
| Type | Reflective Sensors |
| Web Features | Universal Voltage: 12-240 VDC, 24-240 VAC Up to 50 m Thru-Beam Sensing Distance Spring Up Screw Terminal for Easy Wiring IP67 Protection Time Delay Functions: One-Shot, On, Off Delay 3 A Relay Contacts (NO/NC) |
Overview
These high-quality photoelectric sensors are offered in four sensing modes: throughbeam, background suppression, diffuse and polarized retro reflective. Long distance sensing ranges as far as 50 meters with through-beam models and as close as 1 meter with diffuse models. They also support 12-240 VDC and 24-240 VAC, a much wider range of power at a great low price compared to most competitor sensors.
SA1U sensors utilize a spring up screw terminal making wiring easy. Customers can use almost any conductors and no special cables (M8 or M12) are required. These switches are assembled in a fully automated robotic process and are UL/c-UL listed, CE marked and IP67 rated, making them ideal for use in wet environments such as bottling and food processing industries. SA1U is also perfect for direct sunlight applications.
