Technical Specifications

• Maximum Power at STC (Pmax): 50W.
• Optimum Operating Voltage (Vmp): 17.8V.
• Optimum Operating Current (Imp): 2.81A.
• Open-Circuit Voltage (Voc): 22.00V.
• Short-Circuit Current (Isc): 3.01A.
• Solar Module Efficiency (%): 14.01.
• Dimension: 695 mm x 510 mm x 25mm.
• Weight: 5kg.
• Operating Temperature: -40˚C to 85˚C.
• Maximum System Voltage (DC): 1000.
• Maximum Series Fuse Rating: 10A.
• Power Tolerance: /-3%.
• Cell Type: Poly.
• Number of Cells: 36 Cell (156 x 156 series)
• MC4 connectors not supplied

STC: Irradiance 1000W/㎡, Modules Temperature 25℃, AM=1.5

Please note that panel dimensions and specifications are subject to change. Please double check with us that they are correct at time of purchase.
